KLM MD-11 - Probe and Sensor Locations

MD-11 Flight Crew Operations Manual
k
Ice and Rain Protection -
Components
Ice.20.5
Probe and Sensor Locations
PITOT TUBES (3)
NOT USED
CAPTAIN
NOT USED
FIRST OFFICER
TOTAL AIR
TEMPERATURE PROBE
ANGLE OF ATTACK SENSOR (2)
RIGHT AND LEFT SIDE
ALTERNATE STATIC PORT (2)
RIGHT AND LEFT SIDE
STATIC PORT (2)
RIGHT AND LEFT SIDE
DB1-2-1786
October 02, 2006
