MD-11 Flight Crew Operations Manual
k
Landing Gear and Brakes -
Controls and Displays
Land.30.13
Config Cue Switch
1. CONFIG Cue Switch - white
Illuminates white when CONFIG alert is displayed on EAD.
When pushed:
• MASTER WARNING or MASTER CAUTION lights will extinguish.
• A reminder message replaces the EAD alert, except for Level 3 alert.
• Configuration synoptic comes into view on the SD.
Some Level 1 alerts are maintenance alerts that appear on the SD STATUS
page only. These maintenance alerts will not illuminate the cue switch or the
MASTER CAUTION lights.
LB1-3-0168
1
AFT
PEDESTAL
ENG
HYD
ELEC
AIR
FUEL
CONFIG
MISC
STATUS
CONSEQ
ND
BRT
1
2
3
4
5
6
OFF
October 02, 2006
