MD-11 Flight Crew Operations Manual
k
Air -
Controls and Displays
Air.30.7
CARGO TEMP Control Panel
1. FWD CARGO TEMP Selector
Regulates the temperature in the forward cargo compartment.
LO - 4.4° C.
HI - 21.1° C.
OFF - Heating system is off.
2. AFT CARGO TEMP Selector
Regulates the temperature in the aft cargo compartment.
COLD - 4.0° C.
HOT - 35° C.
OFF - Heating system is off.
DB1-2-1930
TEMP
CARGO
OFF
OFF
HOT
COLD
FWD
AFT
LO
HI
1
2
FORWARD OVERHEAD PANEL
October 02, 2006
