KLM MD-11 - GPWS;EGPWS Envelope (Sheet 4)

MD-11 Flight Crew Operations Manual
k
Warning and Alerting -
Controls and Displays
Warn.30.10
GPWS/EGPWS Envelope (Sheet 4)
CAG(IGDS)
0
400
800
1200
1600
2000
0
400 800 1200 1600 2000 2400
"TOO LOW TERRAIN"
"TOO LOW TERRAIN"
0
30
500
1000
1500
2000
2500
0 1 2 3 4
"GLIDE SLOPE" (SOFT)
GLIDE SLOPE DEVIATION - DOTS BELOW BEAM
MODE 5 - DESCENT BELOW GLIDE SLOPE
"GLIDE SLOPE" (HARD)
MINIM UM TERRAIN CLEARANCE - FEETMINIMUM TERRAIN CLEAR
MODE 4C - UNSAFE TERRAIN CLEARANCE -
GEAR UP, FLAPS UP
<190 KTS
>250 KTS
RADIO ALTITUDE - FEET
LB1-3-0198
October 02, 2006
