MD-11 Flight Crew Operations Manual
k
Instrumentation and Navigation -
Controls and Displays
Inst.30.17
TCAS - Off Scale RA on PFD
CAG(IGDS)
GREEN
RED
CLIMB
3700
8500
3.7
29.98
GREEN
RED
29.98
2000
3.6
DESCEND
-3600
Corrective RA
Up advisory
Climb 3700 fpm
Corrective RA
Down advisory
Descend 3600 fpm
5000
5500
4500
4000
6000
5000
5500
4500
4000
6000
4
3
2
1
3
0
1
2
4
4
3
2
1
3
0
1
2
4
achieved.
The limits of the PFD vertical speed tape are 4000 fpm climb and 4000 fpm descent.
If an RA is more than 3000 fpm up/down, an appropriate climb or descend doghouse
lines forming the tip of the arrow are red and turn green when the required V/S is
box appears. The required V/S appears in the box with the word CLIMB or DESCEND.
The box and text are initially green, however, if desired V/S is not met the two
LB1-3-0322
Voice warning:
maintain vertical speed,
maintain (change 7)
Voice warning:
maintain vertical speed,
maintain (change 7)
