MD-11 Flight Crew Operations Manual
k
Instrumentation and Navigation -
Controls and Displays
Inst.30.33
Electronic Chronometer
1. DATE Button
Push to display date in window. Push again to display UTC time. If
chronograph is counting, elapsed time will be displayed in lower window for
2 seconds upon returning to UTC time.
2. UTC Selector
Sets date or UTC time in upper window. Function is dependent on display of
date or time in the window.
RUN - Starts time.
HLDY - Hold time/Set year.
SSM - Slow slew minutes/Set month.
FSD - Fast slew hours/Set day.
3. ET Selector
RUN - Stars elapsed time in lower window.
HLD - Records elapsed time.
DB1-2-1859
CHR
DATE
DAY MO/YEAR
50
10
U
T
C
ET/CHR
40
20
30
RUN
HLD
E
T
RESET
RUN
UTC
DY
SM
SD
3
4
2
1
RIGHT OBSERVER STATION
October 02, 2006
