Electrical -
Functional Schematic
Elec.50.4
Emergency Power
LEFT EMERGENCY
POWER ONLY
AIRCRAFT
BATTERY
BATTERY BUS
L EMER DC BUS
STATIC
INVERTER
L EMER AC BUS
ADG - AIR-DRIVEN GENERATOR
TR - TRANSFORMER RECTIFIER
LEFT EMERGENCY
BUSES-BATTERY
POWER AND ADG IN
THE HYDRAULIC MODE
ADG
LEFT AND RIGHT
EMERGENCY BUSES
ADG IN THE
ELECTRICAL MODE
AIRCRAFT
BATTERY
ADG
L EMER AC BUS
BATTERY BUS
L EMER DC BUS
BATTERY BUS
L EMER AC BUS
BATTERY
CHARGER
R EMER AC BUS
BUSES-BATTERY
TR-3
AIRCRAFT
BATTERY
L EMER DC BUS
R EMER DC BUS
BUS
BAT DIRECT
BUS
BAT DIRECT
BUS
BAT DIRECT
ADG BUS
ADG BUS
