Korg Oasys User Manual

Routing effect settings
191
15.PresstheOn/Offbuttontoturnonthemaster
effect.
Eachtimeyoupressthebutton,themastereffect
willbeswitchedon/off.WhenOff,theoutputofthe
mastereffectwillbemuted.
16.Use“Return1”and“Return2”toadjusttheoutput
levelsofthemastereffects.
Note:Foreach
effect,theWetvalueoftheWet/Dry
parameteristheoutputlevelattheeffect.The
returnvalueismultipliedwiththis(“Return”=127
willbex1.0)todeterminetheactualoutputlevelof
themastereffect.
17.SelecttheMFX1andMFX2pages,andsetthe
parametersforeachselected
effect.
Fordetailsonthe“ProgramEffectssettings”step
11.
Total Effects
18.Ifyouuse“BusSelect(IFX/Indiv.OutAssign)”to
chooseL/Rastheoscillatoroutput,orifyousetthe
post‐IFXBusSelecttoL/R,thesignalwillbeinput
tothetotaleffect.
Theoutputfromthemastereffectsisinputtothe
totaleffectsviathe“Return1”and“Return2”
settingsoftheProgramP9:Master/TotalEffect–
Routingpage.
Afterbeingprocessedthroughthetotaleffects,the
signalisoutputfromtheAUDIOOUTPUT(MAIN)
L/MONOandRoutputs.
19.AccesstheProgramP9:Master/TotalEffect–
Routingpage.
20.ChoosethedesiredtotaleffectforTFX1andTFX2.
Theprocedureisthe
sameaswhenselectingan
inserteffect.(Seestep7)
21.PresstheOn/Offbuttontoturnthetotaleffectson.
Thetotaleffectwillbeswitchedon/offeachtime
youpressthebutton.IfthisisOff,theresultwillbe
thesameasif000:NoEffectisselected.Theinput

soundwillbeoutputwithoutchange.
22.AccesstheTFX1orTFX2pages,andeditthe
parametersofeacheffecttoadjustthefinalsound
asdesired.
Fordetailsonthe“ProgramEffectssettings”step
11.
Using effects in Combinations and Songs
InCombination,andSequencermodes,youcan
specifytheroutingofeachtimbre/tracktotheinsert
effects,mastereffectsandtotaleffects.Thesesettings
aremadeinthesamewayineachofthesemodes.We
willbeusingtheexampleofCombinationmodeinour
explanationhere.
Routing
1. AccesstheCombinationP8:InsertEffect–
Routing1page.
2. Use“BusSelect(IFX/Indiv.OutAssign)”tospecify
thebustowhicheachtimbrewillbeoutput.
ChooseIFX1ifyouwanttosendtheoutputofa
timbretoinserteffect1.
Therouting,inserteffects,andchainsettingsare
showngraphicallyinthe
upperpartofthedisplay
screen.Inthisexample,T01(timbre1)usesIFX1and
2.T02usesIFX2,T03usesIFX3and4,T02andT05
useIFX4,andT06andT07useIFX5.
3. UseSend1andSend2tospecifythesendlevelof
eachtimbretothemastereffects.
Thiscanbesetonlyif“BusSelect(IFX/Indiv.Out
Assign)”issettoL/RorOff.
Note:Theactualsendlevelisdeterminedby
multiplyingthisbythe“Send1”or“Send2”
settingsforoscillators1and2withintheprogram
selectedbythetimbre.Iftheprogramparameter
“Send
1”or“Send2”issetto0,theresultinglevel
willstillbe0evenifyouraisethissendlevel.
If“BusSelect(IFX/Indiv.OutAssign)”issettoIFX1–
12,thesendlevelstothemastereffectsaresetby
Send1andSend2(InsertFXpage)followingthe
inserteffects.
4. AccesstheCombinationP8:InsertEffect–Routing
2page.
BusSelect(IFX/Indiv.OutAssign)isthesameasin
theRouting1page.Youcansetitfromeitherpage.
FXControlBussendstheoutputofthetimbretoan
FXControlbus.Usethiswhenyouwanttheaudio
input
toaneffecttobecontrolledbyanothersound.
TherearetwoFXControlbuses,whichgivesyoua
greatdealoffreedomforcontrollingeffectsfreely.
(SeePGp.575“4.FXControlBus”)
RECBussendstheoutputofthetimbretoaREC
bus.IntheP0–AudioInput/Sampling
page,youcan
settheSamplingSetupSourceBustoaRECbus,
andsamplethesignalthatissenttotheRECbus.
Usethisifyouwanttosampleonlythesoundofa
specifictimbre.
Note:SequencermodehassettingsforMIDIRouting
1/2andAudioRouting1/2.
Thesespecifytheeffect
routingforMIDItracksandaudiotracks.
InSequencermode,youcanalsochooseaRECbus
astheRECSourceforeachtrackintheP0–Audio
TrackMixerpage,sothatthesignalssenttotheREC
bus(es)canberecordedtotheharddisk.

Korg Oasys Specifications

General

Type	Workstation
Timbrality	16 parts
Velocity Sensitivity	Yes
Aftertouch	Yes
RAM	1GB
Synthesis Types	HD-1, AL-1, CX-3, STR-1
Oscillators	Varies by synthesis type
LFO	Multiple LFOs per program
Filter	Varies by synthesis type
Effects	12 insert effects, 2 master effects
Sequencer	16-track MIDI
Sampling	Yes, with 16-bit/48kHz resolution
Display	10.4-inch color touch screen
Keyboard	88-key or 76-key weighted action
Storage	40GB internal hard drive
Connectivity	MIDI In/Out/Thru, USB, S/PDIF
