Appendices
234
Audio Outputs
Analog Main outputs: L/Mono, R
Individual outputs: 1–8
1/4” TS (Mono), unbalanced, Master Volume slider controls only L/Mono and R
Output Impedance 1.1k¾ stereo; 550¾ mono (L/Mono only)
Nominal Level +4.0 dBu
Maximum Level +16.0 dBu
Load Impedance 10 k¾ or greater
Headphone output 1/4” TRS (Stereo), Master Volume slider (link with Main output L/Mono)
Output Impedance 33¾
Maximum Level 50+ 50 mW @33¾
Digital Optical S/P DIF Format: 24 bit, S/P DIF IEC60958 EIAJCP-1201
Sample Rate: 48 kHz or 96 kHz
Digital output of the same signals as L/Mono and R
EXB-DI Digital Interface
Board (Optional)
ADAT output: 24-bit, 8 channels, 48 kHz Sample rate
BNC Word Clock input
Digital output of the same signals as Audio Output (Individual) 1–8; L/R Bus Indiv. Assign allows
L/Mono and R to be output
Audio Inputs
Analog Audio inputs 1, 2 Combination XLR and 1/4” TRS (mono), balanced
MIC/LINE input level switches 1 & 2.
LEVEL knobs 1 & 2.
Phantom Power On/Off 1 & 2.
Input Impedance XLR-3-31: 4 k¾
TRS Phone: 10 k¾
Nominal Level: LINE +4 dBu (LEVEL knob = min)
–36 dBu (LEVEL knob = max)
Nominal Level: MIC –22 dBu (LEVEL knob = min)
–62 dBu (LEVEL knob = max)
Maximum Level: LINE +16 dBu (LEVEL knob = min)
–24 dBu (LEVEL knob = max)
Maximum Level: MIC –10 dBu (LEVEL knob = min)
–50 dBu (LEVEL knob = max)
Source Impedance 600¾
Signal to noise ratio 95 dB (typical)
Dynamic range 95 dB (typical)
Crosstalk 95 dB, at 1 kHz (typical)
Audio Inputs 3, 4 1/4” TS (Mono), unbalanced
Input Impedance 10 k¾
Nominal Level +4.0 dBu
Maximum Level +16 dBu
Source Load Impedance 600¾
Signal to noise ratio 100 dB (typical)
Dynamic range 100 dB (typical)
Crosstalk 100 dB, at 1 kHz (typical)
Digital Optical S/P DIF Format: 24 bit, S/P DIF IEC60958 EIAJCP-1201
Sample Rate: 48 kHz or 96 kHz
Control Inputs DAMPER (Supports piano-style half-damper pedals as well as standard foot switches)
ASSIGNABLE SWITCH, ASSIGNABLE PEDAL
MIDI IN, OUT, THRU
USB 4 USB 2.0 High-Speed ports (supports 480 Mbps) (TYPE A) with Mass Storage Device support, for connecting external hard drives,
flash memory, etc.
Disk Drive HDD (2.5" 40 GB), CD-R/RW
RAM memory 1 GB, expandable to 2 GB
* RAM memory is used for the operating system, PCM ROM, user sampling RAM, and optional EXs.
Power AC Power Supply terminal, POWER On/Off switch
Dimensions
(W x D x H)
88 Keys: 1,458 x 484 x 135 (mm)
76 Keys: 1,266 x 484 x 135 (mm)
Weight 88 Keys: 32.1 kg
76 Keys: 25.7 kg
Power Consumption 88 Keys: 130W
76 Keys: 130W
Accessories AC cable, Owner’s Manuals, Restore CDs
