Kyocera TASKalfa 8002i

2NJ/2RK
2-148
(1-3) Side Paper Feeder (PF-7120)
Figure 2-268
1
5
6
7
8
9
9
11
10
22
19
17
18
21
16
2
3
4
24
2
13
20
23
15
14
12
1. Outer case
2. Inner frame
3. Bottom pad
4. Bottom cushioning material
5. Main unit
6. Main unit cover
7. Front right stay
8. Front left stay
9. Rear stay
10. Upper sheet
11. Upper pad
12. Size label
13. Attachment A
14. Guide film A
15. Guide film B
16. Lock support plate A
17. Switch lever
18. Lock support plate B
19. Screws (M4x8 P-tite)
20. Screws (M4x8 S-tite)
21. Cover plate
22. Attachment B
23. Spanner
24. Installation guide
