Kyocera TASKalfa 8002i

2WA/2NJ/2RK
4-151
(5-6) Detaching and reattaching the IH unit
Procedures
1. Pull out the conveying unit (a).
2. Remove the screw (b)(M3x8) and
remove the fuser wire cover (c).
3. Disconnect two connectors (d).
Figure 4-223
a
b
c
d
d
14j0066
