(2-2) Part name table (PWB)
No. Name used in service manual Name used in parts list Part. No. Refer
ence
1
Main PWB
PARTS PWB MAIN ASSY SP
PARTS PWB MAIN ASSY EU SP
302NJ9401_
302NJ9414_
2
Engine PWB
PARTS PWB ENGINE ASSY SP
90ppm 302WA9401_
70/ 80ppm 302NJ9406_
3
Power source PWB
PARTS UNIT LOW VOLTAGE 100 SP
PARTS UNIT LOW VOLTAGE 200 SP
302ND9461_
302ND9462_
4
High-voltage PWB
PARTS UNIT HIGH VOLTAGE MAIN
SP
302NJ9409_
5
CCD PWB PARTS ISU ASSY H SP 302ND9311_
6
LED PWB PARTS MOUNT LED ASSY SP 302V69308_
7
Front PWB
PARTS PWB FRONT MONO ASSY
SP
302NJ9407_
8
Feed PWB PARTS PWB FEED ASSY SP 302NJ9411_
9
Relay PWB PARTS PWB JUNCTION ASSY SP 302K99420_
10
LSU relay PWB
PARTS PWB LSU JUNC MONO
ASSY SP
302NJ9408_
11
APC PWB
LK-6722: 90ppm
LK-6721: 80ppm
LK-6720: 70ppm
302WA930_
302NJ9307_
302RK9301_
12
PD PWB
LK-6722: 90ppm
LK-6721: 80ppm
LK-6720: 70ppm
302WA930_
302NJ9307_
302RK9301_
13
Drum PWB DK-6720 302NJ9302_
14
IH PWB
PARTS IH BOX ASSY (M/J) SP
PARTS IH BOX ASSY (M/E) SP
302NH9419_
302NH9418_
15
RFID PWB PARTS PWB RFID ASSY SP 302NJ9412_
16
KUIO relay PWB PARTS PWB KUIO ASSY SP -
17
PF main PWB
PARTS PWB FRONT DECK ASSY
SP
302NH9430_
18
BR main PWB PARTS PWB NFC ASSY SP 302K99483_
19
JS main PWB PARTS PWB JOB SEPA ASSY SP 302K99460_
20
DP relay PWB PARTS PWB DPIF ASSY SP 303R89405_
21
Operation panel main PWB PARTS PWB PANEL MAIN ASSY SP 302RH9403_
22
Operation panel key PWB PARTS PWB OPERATION ASSY SP 302RH9404_
23
USB hub PWB PARTS PWB USB HUB ASSY SP 302RH9402_
24
Fuser high-voltage PWB
PARTS UNIT HIGH VOLTAGE
FUSER SP
302ND9469_
