2WA/2NJ/2RK
4-7
2. Pull out the upper cassette (a) from the
main unit (b) and remove it in the direc-
tion of the arrow.
Figure 4-2
3. Release the hook (a) and remove the
forwarding pulley (b) from the shaft.
4. Release the hook (a) and remove the
paper feed pulley (c) from the shaft.
Figure 4-3
a
b
To Next Page
