ipLDK-60 Issue 2.0
Admin Programming Manual July, 2010
25
PGM
111
Flex
Btn
Description Default Values
No Touch
Answer
7 When enabled (On), transferred CO calls are automatically connected to the station
if in the HF or Privacy Intercom Signal Mode.
0 (Off) 0 = Off
1 = On
Page Access 8 When enabled (On), the station is allowed access to the System paging facilities to
send page announcements.
0 (Off) 0 = Off
1 = On
Ring Type 9 This parameter defines the ring tone the station will receive for incoming calls.
Ring type 1 – 1000 & 1020 Hz
Ring type 2 – 890 & 910 Hz
Ring type 3 – 1260 & 1280 Hz
Ring type 4 - 800 & 820 Hz
1 (Ring Type 1) 1 = Ring Type 1
2 = Ring Type 2
3 = Ring Type 3
4 = Ring Type 4
Speaker Ring 10 This parameter determines which device will receive ring, the speaker, headset, or
both.
1 (Speaker) 1 = Speaker (S)
2 = Headset (H)
3 = Both (B)
Speakerphone 11 When enabled (On), the station speakerphone will be enabled and available for use. 1 (On) 0 = Off
1 = On
VMIB Slot
12
This parameter identifies the slot of the VMIB for use by the station. Not available,
the ipLDK-60 has only one available VMIB slot.
N/A Only one available
Intercom
Tenancy Group
13 This parameter assigns the Intercom Tenancy Group for the station. A ‘0’ value is no
group assignment.
1 (Grp 1) 1 - 5
Error Tone for Tel
Answering
Device (TAD)
14 When enabled (On), busy tone is sent to the SLT port in place of error tone. This
allows a TAD to recognize disconnect supervision.
0 (Off) 0 = Off
1 = On
SLT Flash Drop 15 This parameter determines the treatment of active calls when the user momentarily
activates the hook-switch (Flash).
0: Disabled, the active call is placed on hold and the user receives dial tone,
recall is provided if the user hangs up.
0 (Disable) 0 = Disable
1 = Flash Drop
2 = Flash ignore
3 = Hold Release
