ipLDK-60 Issue 2.0
Admin Programming Manual July, 2010
85
PGM
161
Flex
Btn
Description Default Values
cadence is 0.4s on/ 0.2s off/0.4s on/4s off. When set to ‘No’ the Intercom and CO
line ring cadences are reversed.
Reserved 8
ACD Print Enable 9 When enabled (On), ACD (Automatic Call Distribution) Statistics are output at an
interval defined by Flexible button 10 and 14.
0 (Off) 0 = Off
1 = On
ACD Print Timer 10 This parameter defines the time between outputs of the ACD Statistics (Flexible
button 9) from 001 to 225 units, where the units (seconds or hours) are defined by
Flexible button 14.
001 001 ~ 225
ACD Clear
Database after
Print
11 When enabled (On), the system will clear data from the ACD statistics after output of
ACD reports.
0 (Off) 0 = Off
1 = On
VIMB Prompt
Gain
12 This parameter determines the gain used for playback of VMIB announcements. 08 00 ~ 31
CLI Information
at VM SMDI
13 When enabled (On), the system will send the CLI associated with the call to the
external VM if SMDI signaling is enabled, DIP SW 1-position 2. Not available in
ipLDK-60.
0 (Off) 0 = Off
1 = On
ACD Print Timer
Unit
14 This parameter defines the unit of measure for the ACD Print Timer, Flexible button
10.
0 (Seconds) 0 = Seconds
1 = Hours
Set VM SMDI
Type
15 This parameter determines if SMDI signaling for an external Voice Mail is Type I or
Type II. Not available in ipLDK-60.
0 = Type I
1= Type II
Incoming Toll
Check
16 When enabled (On), the system will apply COS should the user dial after answering
an incoming CO line call.
0 (Off) 0 = Off
1 = On
Auto FAX
transfer CO
17 This parameter defines an analog CO line the system will monitor for incoming call
FAX Tone (1100Hz, 0.5 second On/3 seconds Off repeated). If detected on the CO
line, the call is sent to SLT port 16 in the Basic KSU. Also see PGM 182 Flexible
Not assigned 01 ~ 36 Must be an
Analog CO line.
