WIPER AND WASHER
T63
T
7. Verify that the rear wiper stops in the park
position.
• If not as specified, replace the rear wiper
motor.
End Of Sie
REAR WIPER ARM AND BLADE REMOVAL/INSTALLATION
A6E811667420W01
1. Remove in the order indicated in the table.
2. Install in the reverse order of removal.
3. Adjust the rear wiper arm and blade. (See T64
REAR WIPER ARM AND BLADE
ADJUSTMENT)
Rear Wiper Arm Installation Note
1. Clean the rear wiper arm connector shaft using a
wire brush before installing the rear wiper arm.
End Of Sie
A6E8116W119
A6E8116W133
1Cap
2Nut
3 Rear wiper arm (See T63 Rear Wiper Arm
Installation Note)
4 Rear wiper blade
5 Rubber brush
A6E8116W112
A6E8116W103
