184 FRONT COVER AND RELAT ED COMPONENTS
Front Cover (Front Half)
Gaskets
1
H06080
2
4
3
Figure 251 Front cover gaskets – front half
1. Front cover (front half)
2. Front cover gasket (coolant)
3. O-ring seal
4. Front cover gasket (oil)
1. Install new front cover coolant and oil gaskets into
the front half of the front cover.
2. Install a new O-ring seal into the front half of the
front cover
EGES-265-2
Read all safety instructions in the "Safety Information" section of this manual before doing any procedures.
Follow all warnings, cautions, and notes.
© 2009 Navistar, Inc.
