FLYWHEEL AND FLYWHEEL HOUSING 387
Special Torque
Table 51 Flywheel and Flywheel Housing Special Torques
Engine mounting bracket bolts
108 N·m (80 lbf·ft)
Flexplate mounting bolts
136 N·m (100 lbf·ft)
Flywheel housing mounting bolts
108 N·m (80 lbf·ft)
Flywheel mounting bolts
136 N·m (100 lbf·ft)
Rear engine mounting bracket bolts
108 N·m (80 lbf·ft)
Special Service Tools
Table 52 Flywheel and Flywheel Housing Special Service Tools
Crankshaft timing disk puller (H-bar) Obtain locally
Dial indicator with magnetic base
Obtain locally
Guide pins Obtain locally
Rear seal installer
ZTSE4637
Slide hammer puller set ZTSE1879
EGES-265-2
Read all safety instructions in the "Safety Information" section of this manual before doing any procedures.
Follow all warnings, cautions, and notes.
