278 CRANKCASE, C RAN KSHAFT, AND CAMSHAFT
Special Torque
Table 39 Crankcase, Crankshaft and Camshaft Special Torques
Camshaft thrust plate bolts 26 N·m (19 lbf·ft)
Crankcase ladder, M12 x 35 122 N·m (90 lbf·ft)
Coolant heater bolt 4.5 - 5.1 N·m (40 - 45 lbf·in)
Crankcase ladder, M10 x 25 63 N·m (46 lbf·ft)
Crankshaft main bearing cap bolt torque and sequence (Torque Procedure for
Torque-to-Yield Main Bearing
Bolts, page271)
Special Service Tools
Table 40 Crankcase, Crankshaft and Camshaft Special Service Tools
Cam gear puller ZTSE4411
Camshaft bushing puller ZTSE2893B
Dial indicator set
Obtain locally
Hot plate
Obtain locally
Nylon brush
ZTSE4389
Plastigage®. Obtain locally
Prussian Blue® Obtain locally
Tap, cylinder head bolt holes
ZTSE4671
Tap se t
ZTSE4386
Stiff nylon brush ZTSE4392
EGES-265-2
Read all safety instructions in the "Safety Information" section of this manual before doing any procedures.
Follow all warnings, cautions, and notes.
© 2009 Navistar, Inc.
