AIRCOMPRESSOR,POWERSTEERINGPUMP,ANDPOWER
TAKE-OFF
415
Special Torques
Table 57 TF 550 and TF 750 Air Compressor and Power Steering Pump Special Torques
Air compressor gear nut
150 N·m (110 lbf·ft)
Air compressor mounting bolts (through front cover), M12 x 80 83 N·m (61 lbf·ft)
Bracket bolt to air compressor, M10 x 25
67 N·m (49 lbf·ft)
Bracket bolt to crankcase, M12 x 25
115 N·m (85 lbf·ft)
Elbow assembly, M10
15-16 N·m (132-141lbf·in)
Elbow fitting assembly, M18 48 N·m (35 lbf·ft)
Hose connector assembly, M18
48 N·m (35 lbf·ft)
Power steering mounting bolts, M10 x 35
57 N·m (42 lbf·ft)
Power steering pump drive nut
90 N·m (66 lbf·ft)
EGES-265-2
Read all safety instructions in the "Safety Information" section of this manual before doing any procedures.
Follow all warnings, cautions, and notes.
© 2009 Navistar, Inc.
