OIL PAN AND OIL SUCTION TUBE 211
Specifications
Table 22 Oil Fill Specifications
Dry engine (after rebuild and new filter) 34 L (36 quarts US)
Wet engine (after oil drain and filter change) 28 L (30 quarts US)
Special Torque
Table 23 Oil Pan and Oil Suction Tube Special Torques
Oil pan drain plug 68 N·m (50 lbf·ft)
Oil heating element assembly (optional) 68 N·m (50 lbf·ft)
Oil pan heater plug 68 N·m (50 lbf·ft)
Oil pan mounting bolts 32 N·m (24 lbf·ft)
Oil suction tube bracket, M10 x 25 63 N·m (46 lbf·ft)
Oil suction tube, M8 x 35 27 N·m (20 lbf·ft)
Special Service Tools
Table 24 Special Tools
Wacker T – 442 RTV sealant
Obtain locally
EGES-265-2
Read all safety instructions in the "Safety Information" section of this manual before doing any procedures.
Follow all warnings, cautions, and notes.
© 2009 Navistar, Inc.
