AIRCOMPRESSOR,POWERSTEERINGPUMP,ANDPOWER
TAKE-OFF
409
Description
The air compressor and power steering pump
assemblies are optional on International® DT 466,
DT 570 and HT 570 Diesel Engines. They can
be configured individually or together depending
on vehicle application requirements. A front cover
mounted Power Take-off (PTO) devise can be used
in conjunction with the air compressor.
AIR COMPRESSOR
Air for braking is supplied by an air compressor
mounted on the lower left side of the engine. It is
gear driven from the lower idler gear located within
the front engine cover.
• Lubrication of the compressor is provided by
a hose connected at the engine oil pressure
sensor port with oil draining back to the crankcase
through an elbow at the bottom of the compressor.
• Filtered air is furnished through an air hose
connected to the air cleaner assembly, and
compressed into a supply tank. When the air
supply tank is full, compressed air is simply
vented to the atmosphere.
• Coolant to the compressor is supplied and
returned through two hoses to ports located
on the left side of the engine crankcase.
POWER STEERING PUMP
The power steering pump assembly is mounted in one
of two following configurations:
A. Without an air compressor, the power
steering pump is mounted onto rear half
of the front cover and is driven by the lower
idler gear that would normally drive the air
compressor.
B. With an air compressor, the power steering
pump is mounted to the air compressor.
The compressor is driven by the lower idler
gear and power is transferred through the
compressor crankshafttodrivethepower
steering pump.
NOTE: For component service procedures other than
removal and installation refer to the International
Service Information Solutions - ISIS® and then
select manufacturer from suppliers tab.
POWER TAKE-OFF
A front cover mounted Power Take-off (PTO)
devise can only be used in conjunction with an
air compressor. See (1171813R1 Front Cover PTO
Adaptation Kit, page487).
Removal
GOVERNMENT REGULAT ION: Engine
fluids (oil, fuel, and coolant) may be a hazard
to human health and the environment.
Handle all fluids and other contaminated
materials (e.g. filters, rags) in accordance
with applicable regulations. Recycle
or dispose of engine fluids, filters, and
other contaminated m aterials according to
applicable regulations.
WARNING: To prevent personal injury or
death, read all safety instructions in
the "Safety
Information" section of this manual.
WARNING: To prevent personal inju
ry or
death, shift transmission to park
or neutral, set
parking brake, and block wheels b
efore doing
diagnostic or service procedur
es.
WARNING: To prevent personal injury or
death, wear safety glasses with side shields.
Limit compressed air pressure to 207 kPa (30 psi).
WARNING: To prevent personal injury or
death, do not let engine fluids stay on your skin.
Clean skin and nails using hand cleaner and wash
with soap and water. Wash or discard clothing
and rags contaminated with engine fluids.
NOTE: Air compressor and power steering pump may
be removed as an assembly depending on servicing
circumstances.
EGES-265-2
Read all safety instructions in the "Safety Information" section of this manual before doing any procedures.
Follow all warnings, cautions, and notes.
© 2009 Navistar, Inc.
