318 ENGINE ELECTRICAL
Figure 484 Injector connector
4. Disconnect the wiring harness connector from
each of the six injectors.
5. Disconnect from the valve cover gasket.
6. Release valve cover harness by unclipping from
the high-pressure oil manifold.
EGES-265-2
Read all safety instructions in the "Safety Information" section of this manual before doing any procedures.
Follow all warnings, cautions, and notes.
© 2009 Navistar, Inc.
