402 DIAMOND LOGIC® EN GINE BRAKE
Figure 645 Oil inlet O-ring
7. Coat new oil inlet O-ring with clean engine oil and
install O-ring in recess in cylinder head.
WARNING: To prevent personal injury or
possible death, have an assistant help remove
or install the high-pressure oil rail when working
within the chassis.
Figure 646 High-pressure oil rail
1. Lift high-pressure oil rail up and place on engine.
Align injector oil inlet adaptors with injector inlets.
EGES-265-2
Read all safety instructions in the "Safety Information" section of this manual before doing any procedures.
Follow all warnings, cautions, and notes.
© 2009 Navistar, Inc.
