NETGEAR ProSafe GSM7248

User Manual for the NETGEAR 7200 Series Layer 2 Managed Switch Software Version 4
10-18 Quality of Service (QoS) Commands
202-10102-01, May 2005
match vlan
This command adds to the specified class definition a match condition based on the value of the
layer 2 VLAN Identifier field (the only tag in a single tagged packet or the first or outer tag of a
double VLAN tagged packet). The VLAN ID is an integer from 1 to 4095.
Default
None
Format match vlan <1-4095>
Mode Class-Map Config
Policy Commands
The 'policy' command set is used in DiffServ to define:
Traffic Conditioning
Specify traffic conditioning actions (policing, marking) to apply to traf-
fic classes
The policy commands are used to associate a traffic class, which was defined by the class
command set, with one or more QoS policy attributes. This association is then assigned to an
interface to form a service. The user specifies the policy name when the policy is created.
The DiffServ CLI does not necessarily require that users associate only one traffic class to one
policy. In fact, multiple traffic classes can be associated with a single policy, each defining a
particular treatment for packets that match the class definition. When a packet satisfies the
conditions of more than one class, preference is based on the order in which the classes were added
to the policy, with the foremost class taking highest precedence.
This set of commands consists of policy creation/deletion, class addition/removal, and individual
policy attributes. Note that the only way to remove an individual policy attribute from a class
instance within a policy is to remove the class instance and re-add it to the policy. The values
associated with an existing policy attribute can be changed without removing the class instance.
The CLI command root is
policy-map.
assign-queue
This command modifies the queue id to which the associated traffic stream is assigned. The
queueid is an integer from 0 to n-1, where n is the number of egress queues supported by the
device.
