Oce plotwave 345 User Manual

[Remove strip] [Top] [Erase a strip from the beginning of the
original.]
From 0 to 400 mm or 0 to 16".
[Bottom] [Erase a strip from the bottom of the origi-
nal.]
From 0 to 400 mm or 0 to 16".
[Left] [Erase a strip from the left side of the origi-
nal. ]
From 0 to 400 mm or 0 to 16".
[Right] [Erase a strip from the right side of the orig-
inal.]
From 0 to 400 mm or 0 to 16".
[Mirror] [On]
[Off]
[When “on”, the image is mirrored along
the vertical axis (the media transport direc-
tion). ]
Advanced settings for scan jobs
194
Chapter 4 - Use the Printing System

Oce plotwave 345 Specifications

General

Resolution	600 x 1200 dpi
Memory	4 GB
Hard Drive	500 GB
Print Technology	Electrophotography LED
Print Speed	6 A1/D prints per minute
Media Handling	Rolls
Maximum Media Width	36 inches
Technology	Océ Radiant Fusing
Media Width	Up to 36 inches
Roll Capacity	Up to 2 rolls
Media Length	Up to 18.3 m (60 ft)
