Environment Settin
g
s
Cha
p
ter 9
Item
Option
(Initial value:
With an
underline)
Function
Ref.
page
Parallel
Commu
nication
Min. Ready
OFF Time (ms)
0 to 1000 ms (in
1 ms unit)
To specify minimum Ready-off time. This function is
effective if the external device cannot detect the Ready
signal change from Off to On due to fast processing speed
and short product switching time.
－
Parallel Reset
Condition
Hold /
Off After Read /
Off Before Read
Choose parallel output signal for resetting (OFF) timing
from the options listed below:
• Hold: Retains up until the next inspection result is
output (initial value)
• Off After Read: Once resets parallel output signal after
capturing the next image
• Off Before Read: Once resets parallel output signal
before capturing the next image.
248
FCT1 Signal Sets the operation of the PV310 when FCT1 signal is
turned on. Initial value: Display Camera Image
FCT2 Signal
Display Camera
Image /
Tem p lat e
Setting /CF
Restore
Sets the operation of the PV310 when FCT2 signal is
turned on. Initial value: Template Setting
252
to
256
Re-register
Position
Setting Position
/ Adjusted
Position
To set the position of the re-register areas. Tem p lat
e
Settings
Area Display No
/Yes To switch re-register area display On/Off. For Area Display,
re-register start signal must be input twice
232
Initialize Environment --- To return the configuration data to default settings (except
for language settings)
