ter 9
Item
Option
(Initial value: With
an underline)
Function
Ref.
page
Output
Digits
1 to 11 To specify the digit number of output data.
Unused
Digits
Comma
separated/Filled
with '0'
To set a process when the output digit number is less
than output digit number.
259
Type
Switch
Signal
Parallel
/ Computer
Link
To select parallel I/O or reference data stored in the
specified register to input a type switch signal in
Computer Link mode.
(Only when the Output Setting is set to “Computer
Link”.)
Register
number for
Type
number
0
to 9999 To specify the register number to store the number of
type switch signal that is input through Computer Link.
(Only when the Type Switch Signal is set to “Computer
Link”.)
288
PLC
Model
Panasonic FP/
MELSEC A+Q/
MELSEC FX/
OMRON C + CV +
CS1 / AB SLC /
MICREX SX
Sets a PLC type for communicating in Computer Link
communication mode.
(Only when the Output Setting is set to “Computer
Link”.)
Start
Register
0 to 9999 Specifies the top number of the target PLC data
register to which data are output (available only if
Output Setting = Computer Link).
Timeout
(ms)
0 to 20000 ms
(Initial value:5000)
To limit the response time from PLC (available only if
Output Setting = Computer Link)
General Outpu
t
Data Type 16-bit/ 32-bit To specify an output data length in the Computer Link
communication mode.
283
Handshak
e
No/Yes No: 8 Judgment formulas JD01 to JD08 are output to
an external device.
Yes: The PV310 outputs the items (Scan, Judgment,
Num. Calcu., and Statistics) that have been set to
output to the external device
Data Type 8 bit/16 bit/32 bit To set output data length (available only if Output
Setting = Computer Link)
242
Delay
Time
300 to 20000 μs
(Initial value: 5000)
To set the interval of image output.
Data
Output
Settings
Parallel Outpu
t
Timeout 0 to 20000 ms
(Initial value: 300)
To limit the response time (up to ACK signal receive)
from PLC during handshake
247
Comma separated To Insert a comma to separate between the items.
This function does not fix the number of digits of the
items in the commands.
Command -
Format
Fixed Length To fix the number of digits all the items in the
commands to four digits.
Command -
Unused Digits
Filled with 'Blanks'
/ Filled with '0'
Format: For less than 4-digit command, select whether
the command is replaced with a space or “0” when
"Format" is set to "Fixed Length".
259
Serial
Commun
ication
RS232C Baud Rate (bps),
Bit Length, Stop
Bit, Parity, Flow
Control
Select a condition for RS-232C communication with
the external device
260
