RS-232C Communication
Reading Max/ Min slice level ([%L])
This command is for reading Max. and Min. values by specifying a binary group A-H. The slice level of currently
selected product type can be read on PV310.
Communication Direction Command / Description
From external device to PV310
% L ? ? CR
??: 01 to 08 (Specify the number of Slice Level in 2-digit form)
Slice Level A B C D E F G H
Specified No. 01 02 03 04 05 06 07 08
Serial Communication- Command: Comma separated
% L ?? , aaa , bbbCR
?? : 01 to 08 (Slice Level No.: 2 digits)
aaa : 000 to 254 (Slice Level-min.: 1 to 3 digits)
bbb : 001 to 255 (Slice Level-max. 1 to 3 digits)
Response: Normal
Serial Communication- Command: Fixed Length
% L ??aaaabbbbCR
?? : 01 to 08 (Slice Level No.: 2 digits)
aaaa : 0001 to 0255 (Specify Slice Level-Max. in 4-digit form.)
bbbb : 0000 to 0254 (Specify Slice Level - Min. in 4-digit form.)
Response: Error
% U CR
Cause:
Command in the unspecified form or not provided was received.
Examples:
- %L1
C
R
(any other checker number than 01 - 08 was specified)
- %B01
C
R
(not provided command)
