View Range Table - Standard Camera: ANM832
Lens
View range
(mm)
ANM8850
ANM88501
AANB847L
(*1
f=50 mm
ANB846NL
ANM88251
f=25 mm
ANB845NL
ANM88161
(*1
f=16 mm
ANB 843L
f=8.5 mm
ANB842L
f=6 mm
Resolution
(µm/pixel)
Ver. Hor. WD
Adapter
ring
WD
Adapte
r ring
WD
Adapter
ring
WD
Adapte
r ring
WD
Adapter
ring
Ver. Hor.
1 1.1 59 182 2.1 2.1
2 2.1 73 93 4.2 4.2
3 3.2 87 64 6.3 6.2
4 4.3 101 49 8.3 8.3
5 5.3 115 40 31 22 10 10
7.5 8.0 150 28 49 16 16 16
10 10.7 186 22 66 13 31 10 21 21
12.5 13.3 221 19 84 12 42 9.5 26 26
15 16.0 256 16 101 10 53 8.5 31 31
20 21.3 326 13 137 9 76 7.5 30 6.5 42 42
30 32.0 467 10 207 8 121 6.5 54 6 32 5.5 63 62
40 42.7 608 9 277 7 166 6 78 5.5 49 5.5 83 83
50 53.4 749 8.5 348 6.5 211 6 102 5.5 66 5 104 104
75 80.1 1101 7 524 6 323 5.5 162 5 108 5 156 156
100 106.8 1452 6.5 700 5.5 436 5.5 221 5 150 5 208 208
150 160.2 2156 6 1052 5.5 661 5 341 5 235 5 313 313
200 213.6 2860 5.5 1403 5 886 5 461 5 319 5 417 417
250 267.0 1755 5 1112 5 580 5 404 5 521 521
300 320.4 2107 5 1337 5 700 5 488 5 625 625
350 373.8 2459 5 1562 5 820 5 573 5 729 729
400 427.2 2811 5 1787 5 939 5 657 5 833 833
450 480.6 2013 5 1059 5 741 5 938 938
500 534.0 2238 5 1179 5 826 5 1042 1042
600 640.8 2688 5 1418 5 995 5 1250 1250
700 747.6 1657 5 1164 5 1458 1458
800 854.4 1897 5 1333 5 1667 1667
900 961.2 2136 5 1502 5 1875 1875
1000 1068.0 2375 5 1671 5 2083 2083
*1: WD = +11 mm
*2: WD = +4 mm
• Working Distance (WD): The distance from the front of the lens to the
object
• The values in the table are around the focal point of , except as
otherwise noted.
