Item Specification
Processing resolution 512 x 480 pixels (horizontal x vertical)
Processing function Gray: 8 bits 256 gray scale (Binary: 8 groups/product type or camera image)
Settings Through the dedicated keypad
Serial COM1 port: RS-232C (Max. 115200 bps)
Parallel input Removal terminal block, input to 13 inputs
12 to 24V DC, Bi-directional photo coupler
Parallel output Removal terminal block, output to 14 outputs
12 to 24V DC, Photo coupler output (for FLASH, 5 to 24 V DC)
Ethernet Tool port, Media: 10-BASE-T/100BASE-TX Protocol: TCP/IP
External
interface
Memory card slot 1 Slot: Max. 512 MB Compact Flash* memory card (FAT16 format)
Rated voltage 24 V DC
Operating voltage range 21.6 to 26.4V DC (with ripples)
Number of camera connections 2 cameras
Rated power consumption 1.1 A or less (0.9 A or less when connecting one camera)
Operating temperature range 0°C to 50°C (without icing and dew condensation)
Monitor output 1 ch: Color VGA output
Storage temperature -20°C to +60°C (without icing and dew condensation)
Operating/storage humidity
range
35% RH to 75 % RH (without icing and dew condensation at 25°C)
Noise resistance 1000V pulse width 50 ns/1 s (a noise simulator was used.)
Vibration resistance 10 Hz to 55 Hz, one sweep per minute, amplitude 0.75 mm, 30 minutes each in
X/Y/Z direction
Jolt resistance 196 m / s
2
, 5 times each in X, Y and Z directions
Weight Approx. 450 g
* Compact Flash is a trademark of SanDisk Corporation in the United States.
Keypad
Item Specification
Operation buttons ENTER key = 1 and A, B and C key = 1 each
Operating/Storage humidity
range
35% to 75% RH (without icing and dew condensation at 25°C)
Operating temperature range 0°C to 50°C (without icing and dew condensation)
Storage temperature range -20°C to +60°C (without icing and dew condensation)
Weight Approx. 50g (without cables)
