327
Cha
ter 17
General S
ecifications
Double-Speed Random Camera ANM831
Item Specification
Imaging element Read all pixels (interline transfer method), 1/3 inch CCD fixed photo elements
Number of effective pixels Horizontal 659 x vertical 494 pixels, pixel size=7.4 m x 7.4 m (square pixels)
Scanning method Interlace mode (1/60s), 2:1 Interlace (1/120s x 2)
Shutter speed OFF (1/120), 1/200, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/20000s (Controller was
used for setting a shutter speed.)
Lens mount C mount
Rated voltage/ Operating
voltage range
12V DC (supplied from the controller) /10.8 to 13.2V DC
Consumed current 130 mA
Operating temperature
range
Guaranteed temperature range for performance: 0°C to +40°C (without icing and dew
condensation)
Operative temperature range: 0°C to +50°C (without icing and dew condensation)
Storage temperature
range
-30°C to +60°C (without icing and dew condensation)
Operating humidity range Guaranteed humidity range for performance: 50% RH to 70% RH
Guaranteed operative humidity range: 30% RH to 70% RH
(without icing and dew condensation at 25°C)
Storage humidity 25% RH to 90% RH (without icing and dew condensation)
Vibration resistance 10 Hz to 55 Hz, 1 sweep per minute, amplitude 1.2 mm 30 minutes per X, Y, Z
directions
Jolt resistance 700m/s
2
, 3 times each in X, Y and Z directions
Weight Approx. 70g (without camera cables, lenses and a camera mounting plate.)
