Camera Switching Unit: ANPV3700
Item Specification
Function Camera switch 2 camera inputs - 1 camera output (switching by external or
manual signal input)
Camera image division 2 camera input - 1 camera output (UP/Low),
2 camera in
p
ut - 1 camera out
p
ut
(
Left/Ri
g
ht
)
Separation position (Up/Low) 240 (+/- 2) lines
Separation position (Left/Right) 240 (+/- 2) pixels
Camera input 2 inputs (A and B)
Camera output 1 output (OUT)
External switching signal input 1 input, 5 to 24V DC, Bi-directional photo coupler
Settings of dip switches LOCAL/REMOTE, NORMAL/DIV, A/B, UP/LOW and
LEFT/RIGHT
Display Camera switching display, Green LED (A, B)
Rated voltage range 12 V DC (supplied from the PV310 controller)
Consumption current Max. 200 mA
Operating temperature range 0°C to 50°C (without icing and dew condensation)
Storage temperature range -20°C to +60°C (without icing and dew condensation)
Operating/storage humidity range 35% RH to 75 % RH (without icing and dew condensation at
25°C)
Insulation resistance (initial) 100M or more between input part and camera case or DIN rail
(with a 500V DC Megger)
Voltage resistance (initial) 500V AC between input part and camera case or DIN rail for one
minute
Vibration resistance 10 Hz to 55 Hz, one sweep per minute, amplitude 0.75 mm, 30
minutes each in X/Y/Z direction
Jolt resistance 196m/ s
2
, 5 times each in X, Y and Z directions
Weight Approx. 150g (only the main body)
