Color Liquid Crystal VGA Monitor
General Specification
Item ANMX8300 ANMX8301
Rated power 24 V DC
Operating voltage range 22.8 to 25.2 V DC
Power consumption 0.5A or less
Operating ambient temperature 0°C to 40°C
Operating ambient humidity 20%RH to 85%RH (without dew condensation at 25°C)
Storage ambient temperature -20°C to +60°C
Storage ambient humidity 5% RH to 90% RH (without dew condensation at 25°C)
Vibration resistance 10 to 55 Hz (1 sweep per minute), amplitude 0.75 mm, 30 minutes each in
X, Y and Z directions
Jolt resistance 196m/s
2
, three times each in X, Y and Z directions
Noise resistance 1,000 V (P-P) or more, pulse width 50 ns, 1 s between power terminals
(a noise simulator was used.)
Static electricity noise resistance 4,000 V or more
Environmental resistance -------- IP50 (default)
Weight Approx. 1.4 kg Approx. 1.3 kg
Specification for Display Area
Item ANMX8300 / ANMX8301
Display element 6.5 inch TFT liquid crystal
Number of dots 640(H) x 480(V) dots
Display color 262,144 colors
Effective display size 132.5(H) x 99.4(V)
Service life of liquid crystal 65,000 hours or more
Service life of backlight Average: 50,000 hours
Picture signal Analog RGB
Synchronizing signal Horizontal/vertical synchronizing signal
Horizontal operation
frequency
32.3 kHz*
(Number of all pixels: 780)
Vertical operation
frequency
62 Hz
*
(Number of all lines: 520)
Input
signal
Dot clock 25.175 MHz
Interface Analog RGB input, Mini-D-SUB connector 15 pins (female)
Screen adjustment Brightness, vertical and horizontal positions, phase and contrast
*The specified signals should be used for ANMX8300 and ANMX8301. Failure to do so may result in no screen display
and occurrence of noise on the screen, but these are not product failure.
