329
Cha
ter 17
General S
ecifications
Ultra Small Camera ANPVCA1012
Item Specification
Imaging element Interline transfer method. 1/3 inch CCD photo elements
Effective pixels Horizontal 768 x vertical 494 pixels
Scanning method
1/2 interlace
Accumulation method
Frame/Field
Shutter speed OFF (1/30), 1/125, 1/250, 1/500, 1/1000, 1/2000 1/4000, 1/10000 s
Set by the switch on the front face of the camera control unit
Sync method External / Internal switching control
Lens mount Special mount (M10.5, P0.5)
Rated voltage/Operating
voltage range
12 V DC (supplied from PV310) / 10.8 to 13.2 V DC
Consumed current Approx. 400 mA
Operating temperature
range
0 to +40 °C (without icing and dew condensation)
Storage temperature
- 20 to + 60 °C (without icing and dew condensation)
Operating humidity range
20 to 80 %RH (without icing and dew condensation at 25°C)
Storage humidity
20 to 95 %RH (without icing and dew condensation at 25°C)
Vibration resistance 10 to 55 Hz, 1 sweep / 1.5 min,
amplitude 1 mm(camera head)/ 0.25 mm (camera control unit), 30 minutes in each X, Y,
Z direction
Jolt resistance 980 m/s
2
, 3 times in each X, Y, Z direction
Weight Camera(solo): approx. 16 g, Camera control unit: approx. 350 g
Length of camera cable Camera head cable between a camera and a camera control unit: approx. 3 m
