342

Dimensions

Cha

ter 19

Ultra Small Camera: ANPVCA1012

Camera Head

Camera Switching Unit

Lens (For Ultra Small Camera)

ANPVL0401 ANPVL1201

ANPVL3001

Unit: mm
