Panasonic Micro-Imagechecker PV310

To Next Page

To Previous Page

343

Cha

ter 19

Dimensions

Lens (For Standard Camera/ D.S. Random Camera)

ANB846NL ANB845NL

ANB847L ANB843L

ANM8850 ANM88501

Unit: mm
