Remote Control

R&S

ESR

1042User Manual 1175.7068.02 ─ 12

Command Supported subset Function Corresp. HP-

Models

Status

A3 A3 View A HP 8566A/

HP 8568A

available

A4 A4 Blank A HP 8566A/

HP 8568A

available

ABORT

ABORT Stop previous function HP 856xE/

HP 8566B/HP

8568B/HP

8594E

available

ADD

Add HP 8566B/

HP 8568B/

HP 8594E

available

ADJALL ADJALL Adjust all HP 856xE/

HP 8566B/

HP 8568B/

HP 8594E

available

ADJCRT

ADJCRT Adjust CRT HP 856xE/

HP 8566B/

HP 8568B/

HP 8594E

available

ADJIF

ADJIF Auto adjust IF HP 856xE/

HP 8566B/

HP 8568B/

HP 8594E

available

AMB AMB ON|OFF

AMB 1|0

AMB?

Trace A – B -> Trace A HP 856xE/

HP 8594E

available

AMBPL AMBPL ON|OFF

AMBPL 1|0

AMBPL?

HP 856xE/

HP 8566B/

HP 8568B/

HP 8594E

available

ANNOT ANNOT ON|OFF

ANNOT 1|0

ANNOT?

Annotation HP 856xE/

HP 8566B/

HP 8568B/

HP 8594E

available

APB APB Trace A + B -> Trace A HP 856xE/

HP 8566B/

HP 8568B/

HP 8594E

available

GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E
