R&S ESR Series User Manual

Spectrum Measurements
R&S
®
ESR
280User Manual 1175.7068.02 ─ 12
Child Node Attribute Value Parameter Description Mand.
Unit dBm/Hz | dBm |
dBc | dBr | dB
Sets the unit of the stop
value
LimitFailMode Absolute | Relative
| Absolute and Rel-
ative | Absolute or
Relative
If used, it has to be identical
to DefaultLimitFailMode
No
RBW Bandwidth <bandwidth in Hz> "RBW" on page 259 Yes
Type NORM | PULS |
CFIL | RRC
No
VBW Bandwidth <bandwidth in Hz> "VBW" on page 260 Yes
Detector NEG | POS |
SAMP | RMS |
AVER | QUAS
If used, it has to be identical
in all ranges.
No
Sweep Mode Manual | Auto "Sweep Time Mode"
on page 260
Yes
Time <time in sec> "Sweep Time" on page 260 No
Amplitude No
ReferenceLevel Value <power in dBm> "Ref. Level" on page 260 Yes, if the Refer-
enceLevel child
node is used
Unit dBm Defines dBm as unit Yes, if the Refer-
enceLevel node
is used
RFAttenuation Mode Manual | Auto "RF Att. Mode" on page 260 Yes, if the Refer-
enceLevel child
node is used
Preamplifier ON | OFF "Preamp" on page 260 Yes
ASCII File Export Format (Spectrum Emission Mask)
The first part of the file lists information about the signal analyzer and the general
setup. For a detailed description refer to Chapter 6.3.1.6, "ASCII File Export Format",
on page 399.
