Spectrum Measurements
R&S
®
ESR
342User Manual 1175.7068.02 ─ 12
6.2 Configuration
Basic measurement settings that are common to many measurement tasks are descri-
bed here. If you are performing a specific measurement task or using an operating
mode other than Spectrum mode, be sure to check the specific measurement or mode
description for settings that may deviate from these common settings.
6.2.1 Initializing the Configuration – PRESET Key
The PRESET key resets the instrument to the default setting and therefore provides a
defined initial state as a known starting point for measurements.
If the "local lockout" function is active in the remote control mode, the PRESET key is
disabled.
Further information
●
Chapter 6.2.1.2, "Initial Configuration", on page 343
Task
●
Chapter 6.2.1.1, "Presetting the Instrument", on page 342
6.2.1.1 Presetting the Instrument
1. Define the data set for the presetting:
a) To retrieve the originally provided settings file (see Chapter 6.2.1.2, "Initial Con-
figuration", on page 343), deactivate the "Startup Recall" softkey in the "SAVE/
RCL" menu.
b) To retrieve a customized settings file, in the "File" menu, activate the "Startup
Recall" softkey, press the "Startup Recall Setup" softkey, and select the corre-
sponding file.
For details refer to Chapter 10.1, "Saving and Recalling Settings Files –
SAVE/RCL Key", on page 529.
2. Press the PRESET key to perform a preset.
Remote: *RST or SYSTem:PRESet
After you use the PRESET function, the history of previous actions is deleted, i.e. any
actions performed previously cannot be undone or redone using the UNDO/REDO
keys.
