Spectrum Measurements

R&S

ESR

451User Manual 1175.7068.02 ─ 12

Figure 6-32: Adjacent channel power measurement on a CDMA2000

1x signal

Measurement Example 2 – Measuring Adjacent Channel Power of a W-CDMA

Uplink Signal

Test setup:

Signal generator settings (e.g. R&S SMW):

Frequency: 1950 MHz

Level: 4 dBm

Modulation: 3 GPP W-CDMA Reverse Link

Procedure:

1. Set the R&S ESR to its default state by pressing the [PRESET] key.

Advanced Measurement Examples
