R&S ESR Series User Manual

Remote Control
R&S
®
ESR
856User Manual 1175.7068.02 ─ 12
TRACe<n>[:DATA]:X? <TraceNumber>
This command reads the x-values of the selected trace.
Suffix:
<n>
.
1...4
window; For applications that have only one measurement
screen, the suffix is irrelevant.
Query parameters:
<TraceNumber> TRACE1 | TRACE2 | TRACE3 | TRACE4 | TRACE5 | TRACE6
Trace number
Example:
TRACe:DATA:X? TRACE1
Returns the x-values for trace 1.
Usage: Query only
11.5.3.2
Spectrogram
Configuring Spectrograms
Commands useful to work with markers in the spectrogram described elsewhere:
●
CALCulate<n>:SGRam:CLEar[:IMMediate] on page 649
●
CALCulate<n>:SGRam:HDEPth on page 651
●
CALCulate<n>:SGRam:TSTamp:DATA? on page 652
CALCulate<n>:SGRam:COLor........................................................................................ 856
CALCulate<n>:SGRam:CONT.........................................................................................857
CALCulate<n>:SGRam:FRAMe:COUNt........................................................................... 857
CALCulate<n>:SGRam:FRAMe:SELect........................................................................... 858
CALCulate<n>:SGRam:TSTamp[:STATe]..........................................................................858
CALCulate<n>:SGRam[:STATe].......................................................................................858
CALCulate<n>:SGRam:COLor <Color>
This command selects the color scheme of the spectrogram result display.
Suffix:
<n>
.
1...4
Selects the measurement window.
Parameters:
<Color> COLor
RGB colors
RADar
black - green - white
GRAYscale
black and white
*RST: COLor
Remote Commands in Spectrum Analyzer Mode
