Receiver Mode
R&S
®
ESR
192User Manual 1175.7068.02 ─ 12
●
Receiver Input
For more information see Chapter 5.1.3.3, "The Scan Table", on page 146.
Remote command:
See Chapter 11.4.6.2, "Scan Table", on page 674
RF input:
INPut:TYPE on page 672
Prev / Next Range
Selects the scan range to the left or right of the currently selected scan range.
Remote command:
not supported
5.3.7.3 Peak Search
The "Peak Search" tab in the "Test Automation" dialog box contains functionality to
control the peak search.
Peak Search Mode (Peaks Subranges)......................................................................192
No Of Peaks................................................................................................................193
No of Subranges / Peaks per Subrange..................................................................... 193
Peak Excursion........................................................................................................... 193
Margin......................................................................................................................... 193
Select Limit Line..........................................................................................................193
Peak Search Mode (Peaks Subranges)
Selects the peak search mode.
"Peaks"
Looks for a particular number of peaks over the complete scan range.
"Subranges"
Divides the scan range into smaller subranges and looks for a partic-
ular number of peaks in each subrange.
Common Measurement Settings
