R&S ESR Series

Remote Control
R&S
®
ESR
794User Manual 1175.7068.02 ─ 12
CALCulate<n>:STATistics:RESult<Trace> <ResultType>
This command reads out the results of statistical measurements of a recorded trace.
Suffix:
<n>
.
irrelevant
<Trace> 1...6
trace
Parameters:
<ResultType> MEAN | PEAK | CFACtor | ALL
MEAN
Average (=RMS) power in dBm measured during the measure-
ment time.
PEAK
Peak power in dBm measured during the measurement time.
CFACtor
Determined CREST factor (= ratio of peak power to average
power) in dB.
ALL
Results of all three measurements mentioned before, separated
by commas: <mean power>,<peak power>,<crest factor>
The required result is selected via the following parameters:
Example:
CALC:STAT:RES2? ALL
Reads out the three measurement results of trace 2. Example of
answer string: 5.56,19.25,13.69 i.e. mean power: 5.56 dBm,
peak power 19.25 dBm, CREST factor 13.69 dB
Using Gate Ranges for Statistical Measurements
The following commands control gated statistical measurements.
[SENSe:]SWEep:EGATe:TRACe<k>:COMMent................................................................ 794
[SENSe:]SWEep:EGATe:TRACe<k>: PERiod................................................................... 795
[SENSe:]SWEep:EGATe:TRACe<k>:STARt<range>..........................................................795
[SENSe:]SWEep:EGATe:TRACe<k>[:STATe<range>]........................................................ 795
[SENSe:]SWEep:EGATe:TRACe<k>: STOP<range>......................................................... 796
[SENSe:]SWEep:EGATe:TRACe<k>:COMMent <Comment>
Defines a comment for one of the traces for gated triggering.
Suffix:
<k>
.
1...6
trace
Parameters:
<Comment>
Example:
SWE:EGAT:TRAC1:COMM "SlotA"
Remote Commands in Spectrum Analyzer Mode
