Remote Control
R&S
®
ESR
795User Manual 1175.7068.02 ─ 12
Manual operation: See "Gate Ranges" on page 320
[SENSe:]SWEep:EGATe:TRACe<k>: PERiod <Value>
This command defines the length of the period to be traced using gated triggering.
Suffix:
<k>
.
1...6
trace
Parameters:
<Value> <numeric value>
*RST: 0 s
Example:
SWE:EGAT:TRAC1:PER 5ms
Defines the period for gated triggering to 5 ms.
Manual operation: See "Gate Ranges" on page 320
[SENSe:]SWEep:EGATe:TRACe<k>:STARt<range>
<Value>
This command defines the starting point for the range to be traced using gated trigger-
ing.
Suffix:
<k>
.
1...6
trace
<range> 1...3
range
Parameters:
<Value> <numeric value>
*RST: OFF
Example:
SWE:EGAT:TRAC1:STAR1 3ms
Sets the Starting point for range 1 on trace 1 at 3 ms.
Manual operation: See "Gate Ranges" on page 320
[SENSe:]SWEep:EGATe:TRACe<k>[:STATe<range>] <State>
This command activates or deactivates tracing for a specific range using gated trigger-
ing.
Suffix:
<k>
.
1...6
trace
<range> 1...3
range
Remote Commands in Spectrum Analyzer Mode
