Remote Control

R&S

ESR

1046User Manual 1175.7068.02 ─ 12

Command Supported subset Function Corresp. HP-

Models

Status

DIV

Divide HP 8566B/

HP 8568B/

HP 8594E

available

DL DL <numeric_value>

DB|DM

DL DN

DL UP

DL ON

DL OFF

DL?

Display Line HP 856xE/

HP 8566B/

HP 8568B/

HP 8594E

available

DLE DLE ON|OFF Display Line enable HP 856xE/

HP 8566B/

HP 8568B/

HP 8594E

available

DONE DONE

DONE?

Done query HP 856xE/

HP 8566B/

HP 8568B/

HP 8594E

available

DW Write to display and

increment address

available

E1 E1 Peak Search HP 8566A/

HP 8568A

available

E2 E2 Marker to Center Freq. HP 8566A/

HP 8568A

available

E3 E3 Deltamarker Step Size HP 8566A/

HP 8568A

available

E4 E4 Marker to Ref. Level available available

EDITDONE

limit line edit done HP 856xE available

EDITLIML

edit limit line HP 856xE available

GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E
