R&S ESR Series User Manual

Remote Control
R&S
®
ESR
1057User Manual 1175.7068.02 ─ 12
Command Supported subset Function Corresp. HP-
Models
Status
OA OA Output All HP 8566A/
HP 8568A
available
OL OL <80 characters>
OL?
Output Learn String HP 8566A/
HP 8568A
available
OT OT Output Trace Annota-
tions
HP 8566A/
HP 8568A
available
PA PA <numeric_value>,
<numeric_value
Plot command HP 8566A/
HP 8568A
available
PD PD <numeric_value>,
<numeric_value
Plot command HP 8566A/
HP 8568A
available
PH_MKF Spot frequency in Hz HP 856xE available
PH_FMIN Min offset frequency to
be measured
HP 856xE available
PH_FMAX Max offset frequency to
be measured
HP 856xE available
PH_MKA Queries amplitude at the
spot frequency
HP 856xE available
PH_DRIFT 0: for stable signals, 1:
for drifty
HP 856xE available
PH_RLVL Reference level for the
log plot
HP 856xE available
PH_SMTHV Trace smoothing HP 856xE available
PH_VBR Filtering HP 856xE available
PH_RMSPT Amount of data points to
skip when doing the inte-
gration
HP 856xE available
PH_RMSFL Lower integration fre-
quency in Hz
HP 856xE available
PH_RMSFU Upper integration fre-
quency in Hz
HP 856xE available
PH_EXIT Quits phase noise HP 856xE available
PH_F_UDT Updates internal fre-
quency variables
HP 856xE available
PH_LMT_L Apply limits to PH_FMIN
and PH_FMAX
HP 856xE available
PH_MEAS Generates log frequency
plot
HP 856xE available
PH_MKF_D Updates the spot fre-
quency
HP 856xE available
GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E
