R&S ESR Series User Manual

Remote Control
R&S
®
ESR
1062User Manual 1175.7068.02 ─ 12
Command Supported subset Function Corresp. HP-
Models
Status
STB STB Status byte query HP 856xE/
HP 8566B/
HP 8568B/
HP 8594E
available
STOREOPEN STOREOPEN Store Open HP 856xE/
HP 8594E
not available
STORESHORT STORESHORT Store Short HP 856xE/
HP 8594E
not available
STORETHRU STORETHRU Store Thru HP 856xE/
HP 8594E
not available
SUB Subtract HP 8566B/
HP 8568B/
HP 8594E
available
SUM sum of trace amplitudes HP 8566B/
HP 8568B/
HP 8594E
available
SV1…6 SV1…6 Save State HP 8566A/
HP 8568A
available
SWPCPL
2)
SWPCPL SA | SR
SWPCPL?
Sweep Couple HP 856xE/
HP 8566B/
HP 8568B/
HP 8594E
available
SWPOUT
2)
SWPOUT FAV|FAVA|
RAMP
SWPOUT?
Sweep Output HP 856xE/
HP 8566B/
HP 8568B/
HP 8594E
available
T0 T0 Threshold off HP 8566A/
HP 8568A
available
T1 T1 Free Run Trigger HP 8566A/
HP 8568A
available
T2
2)
T2 Line Trigger HP 8566A/
HP 8568A
available
T3 T3 External Trigger HP 8566A/
HP 8568A
available
T4 T4 Video Trigger HP 8566A/
HP 8568A
available
TA TA Transfer A HP 8566A/
HP 8568A
available
GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E
