Spectrum Measurements

R&S

ESR

368User Manual 1175.7068.02 ─ 12

Filter Bandwidth Filter Type Application

10 kHz CFILter

12.5 kHz CFILter CDMAone

14 kHz CFILter ETS300 113 (20 kHz channels)

15 kHz CFILter

16 kHz CFILter ETS300 113 (25 kHz channels)

18 kHz, a=0.35 RRC TETRA

20 kHz CFILter

21 kHz CFILter PDC

24.3 kHz, a=0.35 RRC IS 136

25 kHz CFILter APCO 25-P2

30 kHz CFILter CDPD, CDMAone

50 kHz CFILter

100 kHz CFILter

150 kHz CFILter FM Radio

192 kHz CFILter PHS

200 kHz CFILter GSM

300 kHz CFILter

500 kHz CFILter J.83 (8-VSB DVB, USA); RF ID 14333

1 MHz CFILter CDMAone

1.228 MHz CFILter CDMAone

1.28 MHz, a=0.22 RRC TD-SCDMA

1.5 MHz CFILter DAB

2 MHz CFILter

3 MHz CFILter

3.75 MHz CFILter

3.84 MHz, a=0.22 RRC W-CDMA 3GPP

4.096 MHz, a=0.22 RRC W-CDMA NTT DOCoMo

5 MHz CFILter

20 MHz CFILter

Configuration
