R&S ESR Series User Manual

Remote Control
R&S
®
ESR
650User Manual 1175.7068.02 ─ 12
Manual operation: See "Spectrogram Clear" on page 374
See "Clear Spectrogram" on page 406
DISPlay:WINDow:SGRam:COLor:DEFault
This command sets the color settings for the spectrogram result display to its default
state.
Usage: Event
DISPlay:WINDow:SGRam:COLor:LOWer
<Percentage>
This command sets the lower percentage boundary of the spectrogram.
Parameters:
<Percentage> Statistical frequency percentage.
Range: 0 to 66
*RST: 0
Default unit: %
Example:
DISP:WIND:SGR:COL:LOW 10
Sets the start of the color map to 10%.
Manual operation: See "Color Mapping" on page 406
DISPlay:WINDow:SGRam:COLor:SHAPe <Shape>
This command defines the shape and focus of the color curve for the spectrogram
result display.
Parameters:
<Shape> Shape of the color curve.
Range: -1 to 1
*RST: 0
DISPlay:WINDow:SGRam:COLor:UPPer <Percentage>
This command sets the upper percentage boundary of the spectrogram.
Parameters:
<Percentage> Statistical frequency percentage.
Range: 0 to 66
*RST: 0
Default unit: %
Example:
DISP:WIND:SGR:COL:UPP 95
Sets the start of the color map to 95%.
Manual operation: See "Color Mapping" on page 406
Remote Commands in Receiver Mode
